3d Carving Basic Technique 01


Hi..! it's my first tutorial about 3d Carving, i will explain step by step from basic form, thank you
Click on the image to enlarger > Right click to Save

1. Create a "Plane" > start from  Create Panel > Plane > then Right Click > Convert to Editable Poly > Rotate it a bit, about 40 degree


Buat sebuah "Plane" > mulai dari panel Create > pilih Plane > kemudian Klik kanan > Convert to Editable Poly > putar sedikit sekitar 40 derajat


2. With vertex selection > move all vertex ( see the picture below )  > then Extrude Edges ( select edges + Shift + Drag )

Dengan seleksi Vertex > geser vertex ( lihat gambar di bawah)  > kemudian Extrude Edges ke kanan dan ke kiri ( pilih edges + tekan Shift + kemudian Drag/tarik ke samping )

3. Add some line with "Cut"  ( with vertex selection > Cut )

Tambahkan beberapa garis dengan menggunakan " Cut" ( lewat seleksi vertek > Cut )

4. With Edge selection > select Edges ( see the Picture ) > then Full forward

Dengan seleksi Edge > pilih Edges ( Lihat gambar )> kemudian tarik kedepan

5. Add some line inside the carving with "Cut"

Tambahkan beberapa garis di tengah ukiran dengan "Cut"

6. Select middle Edges > then pull backward

pilih Edges bagian tengah > tarik ke belakang

7. Here the Final Low Poly


8. Final with  "Use NURMS Subdivision" , ( Iterations = 2 ) to smoothing
